Headless form builder API: the contract behind FormFlow

A headless form builder API connects a form definition to a frontend that owns its markup. The useful contract includes the public schema, submission payloads, validation errors, and the behavior of draft and final submissions.

FormFlow applies that boundary to Strapi v5. Editors manage the form in Strapi; the frontend fetches its schema, renders supported fields, and sends values back for server validation. The React and Vue SDKs help bind that contract to your components.

This guide explains what crosses the API boundary and what remains a server or frontend responsibility. For a complete working setup, start with the Strapi v5 and React contact-form tutorial. For the operational decisions around storage and notifications, read the backend behind a website form.

Publish a public form schema, not a database document

A stored Strapi form contains editor settings and private workflow configuration. A public renderer needs a smaller view:

• Title, description, and slug
• Field IDs, submission names, types, and order values
• Labels, options, descriptions, placeholders, and defaults
• Required flags, validation rules, and conditional visibility rules
• Public layout, step, and spam settings

FormFlow returns that projection from:

GET /api/formflow/forms/contact-form

The response wraps the schema in { "data": ... }. For example, the following excerpt shows the public identity and validation shape of one email field; the complete response also includes the other fields and rendering settings:

{
  "data": {
    "title": "Contact",
    "slug": "contact-form",
    "fields": [
      {
        "id": "a83e3b01-ef7b-4d62-8058-93a6a82d9e45",
        "type": "email",
        "name": "email",
        "label": "Email",
        "required": true,
        "order": 1,
        "validation": []
      }
    ]
  }
}

The ID above is illustrative; FormFlow generates IDs when creating fields. Notification recipients, webhook configuration, integration credentials, and captcha secret keys are not part of the public projection. Enabled reCAPTCHA settings expose its public site key and version, not the secret key.

This is a curated response, not a direct serialization of the stored form. Public access also requires a published, active form.

Treat field IDs and submission names as different contracts

A field's id identifies it inside the form definition. Step configuration can reference those IDs. Its name is the key a frontend uses when submitting a value and when displaying a field error.

For the email field above, submit email, not its UUID and not its label. Changing Email to Work email can preserve the payload contract if name stays email.

Renaming email to work_email is a different change. Clients, field bindings, and integrations that use the old name need updating. A stable ID does not make a renamed submission key backward compatible.

Labels and rules are read when a client fetches the schema. Cached pages still need refresh or revalidation, and adding a new field type requires the renderer to support it. A schema-driven frontend needs its own compatibility strategy.

Submit flat JSON values to the form endpoint

When no visible file field holds an uploaded file, the SDK sends JSON to:

POST /api/formflow/forms/contact-form/submit
Content-Type: application/json

The body is a flat object keyed by the configured field names:

{
  "name": "Ada Lovelace",
  "email": "ada@example.com",
  "message": "Hello",
  "_gotcha": ""
}

_gotcha is the default honeypot name and is included when the form's honeypot is enabled. Use the form's configured name if it was changed. The server removes that control field before storing a legitimate submission.

The { "data": ... } response wrapper is not a request wrapper. Wrapping these values in data would not match the form's expected field keys.

You can consume the REST API directly or use the framework-agnostic client:

import { createFormFlowClient } from "@formflowjs/core";

const client = createFormFlowClient({
  baseUrl: "https://cms.example.com",
});

export async function submitContact(values: {
  name: string;
  email: string;
  message: string;
}) {
  const schema = await client.getForm("contact-form");

  return client.submit("contact-form", { schema, values });
}

Replace the example origin with your Strapi origin. The default API prefix is /api/formflow; a customized REST prefix requires the matching client apiPrefix option. The client unwraps successful responses and throws typed errors for unsuccessful requests.

The schema passed to client.submit() drives serialization and field visibility filtering. This low-level client call does not run the form store's client-side validation before posting. The server still validates the stored form definition. Use the form store or framework adapter when you also want local validation and reactive submission state.

Keep the same field names when switching to multipart

A visible file field holding a real File value makes the SDK use multipart/form-data. File parts use field names; checkbox arrays use repeated keys; ordinary values become text parts.

For a form with an attachment file field, a direct request might look like:

curl -X POST http://localhost:1337/api/formflow/forms/contact-form/submit \
  -F 'name=Ada Lovelace' \
  -F 'email=ada@example.com' \
  -F 'message=Please review the attachment' \
  -F '_gotcha=' \
  -F 'attachment=@./example.pdf'

This example assumes attachment exists in the form schema and allows that file. Let curl, the browser, or the SDK set the multipart boundary rather than manually assigning a bare Content-Type header.

Strapi parses text fields into ctx.request.body and uploads into ctx.request.files. FormFlow passes both to its submission service and checks file-specific constraints separately from ordinary values. A valid file-only form can submit without text fields in its body.

Accepted files go through Strapi's upload service. The upload provider determines where they are stored. The transport changes; the relationship between field names and values stays the same.

Recalculate conditional visibility on the server

Hiding a field in React or Vue does not establish what a handcrafted request can send.

Suppose company_name is visible only when customer_type equals business. The server evaluates that condition against the submitted values and the current stored form. Final validation and storage use the visible fields. Hidden values are excluded from the saved data and the normal post-submission notification payload.

The SDK applies its own visibility calculation while rendering and serializing values. The server repeats the decision independently; it does not trust a client's list of visible fields or its copy of the schema.

Required values, email formats, choices, and configured file constraints are checked on the server before a final submission is stored. A stale client can therefore fail after a schema change, such as adding a required field. Client and server validation improve different parts of the workflow; the server is the acceptance authority.

Make draft, step, and final behavior explicit

These requests represent different states:

The paths in this table are relative to /api/formflow. Step validation requires a multi-step form with defined steps. The SDK exposes validateStep() for that request, while its store can manage step navigation and validation.

A partial response is deliberately incomplete: save-and-resume does not enforce all final required-field rules, upload files, or trigger the final submission hooks. It can retain hidden values because a later answer may reveal those fields again. The final request validates again and excludes currently hidden values.

Save-and-resume is an entitled feature, not part of the ordinary free submission path. The API returns HTTP 402 when the license does not permit it. The SDK's savePartial() and loadPartial() methods do not grant an entitlement.

After loading a partial response, the current SDK submits the restored values through the ordinary final-submission path, which creates a new record. That path does not automatically promote or delete the original draft. Resume tokens allow access to a stored partial response; handle them as credentials in your application.

Return field errors that a renderer can use

An invalid email can produce this HTTP 400 response:

{
  "error": {
    "status": 400,
    "name": "ValidationError",
    "message": "Validation failed",
    "details": {
      "errors": {
        "email": ["Invalid email address"]
      }
    }
  }
}

@formflowjs/core converts this into a FormFlowError with code: "validation" and fieldErrors.email. The store merges server field errors into its error state so React and Vue can display them through the same bindings used for local errors.

The client also distinguishes failures beyond field validation:

The actual response status determines the mapping. An unavailable form can be rejected by the active/published route policy; do not assume every such request reaches the controller's HTTP 404 response.

For a rate limit, the SDK can expose a numeric Retry-After value as retryAfter, in seconds. Use that when explaining when a retry is appropriate.

A successful final response contains the configured message and optional redirect URL inside { "data": ... }. The honeypot middleware intentionally returns the same success shape when it discards spam. Test normal persistence by checking the submissions inbox, not just the success response.

Keep React and Vue bindings renderless

The shared core owns schema types, visibility logic, serialization, API errors, validation, and the form store. React subscribes through useSyncExternalStore; Vue exposes reactive state through refs and computed values.

For example, inside a React FormFlowProvider, a field binding can use your own markup:

import { FormFlowField } from "@formflowjs/react";

export function EmailField() {
  return (
    <FormFlowField name="email">
      {(field) => (
        <div>
          <label {...field.getLabelProps()}>{field.field.label}</label>
          <input {...field.getInputProps({ type: "email" })} />
          {field.field.description && (
            <p {...field.getDescriptionProps()}>{field.field.description}</p>
          )}
          {field.invalid && <p {...field.getErrorProps()}>{field.error}</p>}
        </div>
      )}
    </FormFlowField>
  );
}

The provider's schema must contain an email field. The getters connect its value, events, label, description, and error IDs. Explicitly supplying type: "email" gives the native input the appropriate type; the getter does not infer it from the schema.

The adapters ship no component theme or CSS bundle. Your application still needs to map each supported field type to an appropriate control and preserve the props that reach the native element. A renderless SDK keeps styling under your control; it does not make an arbitrary custom widget compatible by itself.

Keep the API contract reviewable as the form evolves

Before changing a public form, check these boundaries:

1. Public projection: are private settings still excluded?
2. Field identity: did a payload key change, or only its label?
3. Transport: do JSON and multipart use the same field names?
4. Visibility and validation: what will a stale or modified client send?
5. Submission state: is this a draft, a step check, or a final response?
6. Errors: can the frontend present the failure without guessing from text?
7. Rendering: can every consuming client render the configured field types?

Those checks make changes to a Strapi form builder easier to assess across its frontend clients. They do not guarantee compatibility automatically; schema changes and renderer updates still need testing together.
